Description
- The Frame is Cast Iron, all the main parts are enclosed, ensuring protection and perfect stability
- Straight line caterpillar feeding with heavy guided chain. Chain blocks are special cast iron with heat treated & precision ground pins
- Nickel chrome steel Saw Arbor with 70 mm OD – dble. keyed quick removal sleeve
- 3 sets of Anti-Kickback Fingers 2 top, 1 bottom
- Powered Rise & Fall to the pressure rollers
- New style round Fence Bar support with quick shift long fence
- Automatic Centralized lubrication system
- Automatic Star-Delta Starter (slow speed start) and low voltage controls
- E style European guard & safety features
- Long fence for control of long material
- Automatic star-delta starter (slow soft-low amperage start) and low voltage controls
| Maximum Working Thickness: 14” Blade | 4.33” (110mm) without short stock attachment |
| 3.74” (95mm) with short stock attachment | |
| 15” Blade | 4.72” (120mm) without short stock attachment |
| Minimum Length | 23” (585mm) without short stock attachment |
| 11.8” (300mm) with short stock attachment | |
| Maximum Cutting Width | 11.8” (300mm) |
| Distance from Column to Center of Chain | 14.17” (360mm) |
| Sawblade Diameter | 8” to 15” (203 to 380mm) |
| Saw arbor Sleeve Diameter (Blade bore) | 70 mm w/ keyways |
| Saw arbor diameter | 50 mm |
| Saw Arbor Speed | 3800 RPM |
| Saw Motor HP | 50 HP – Voltage 460/3/60 |
| Powered Pressure Rollers(Rise/Fall) | ½ HP motor |
| Feed Speeds | 25 – 100 FPM (7.5~30 m/min) |
| Feed Motor HP | 2 HP |
| Dust Hood diameter | 2 @ 6” |
| Table Size | 60″ x 30” (1530x760mm) |
| Table Height from floor | 33.5” |
| Net Weight | 4510 lbs. (2050 kgs) |
| Shipping Weight | 5060 lbs. (2300 kgs) |
| Machine Dimensions | 82.68” 59” x 56 ½” (2100x1500x1435mm) |
